An easy-to-carry device that combines GPS, RFID, and 4G for remote employee monitoring.
Product Description:
ACTIVE TRACK 2 devices are a traditional solution for remote employee monitoring. It is equipped with a GPS and RFID receiver designed to work on the frequencies of the 2G and 4G telecommunications network
Product Features:
- Two-way voice communication. ActiveTrack can be used as a mobile phone. It is possible to connect to 4 numbers;
- Reading tags (checkpoints): the device sends the “Checkpoint” event to the server (depending on the Active Track model, in real time or periodically);
- Panic button: calling for help in emergency situations;
- MAN-DOWN: function of detecting employee’s immobility;
- A-GPS: technology supporting GPS, enabling faster location;
- Tamper alarm: SHOCK function informing about hitting the device;
- TILT: function of detecting the device’s deviation from the programmed position,
- Ability to send SMS directly from the device to a mobile phone;
- Increased durability casing;
- Vibration when transmitting signals;
- Waterproofness of the device;
- Works with ActiveView – a convenient web application enabling online access from almost any place, equipped with GeoTagging (notification when entering a designated, planned zone).
- Operating time on main battery up to 44 hours
Technical Specification:
| Reader type | Proximity RFID |
| Frequency and standard | 125kHz, unique |
| RFID read-out distance | 3-4cm (depends on transponder type) |
| GSM module | U-Blox Leon G-100 (850/900/1800/1900 MHz) |
| GPS module | |
| Channels | 50 channel u-blox 6 engine |
| A-GPS online/offline support | YES |
| Position accuracy | < 2,5 m |
| TTFF hot start acquisition time | < 1 s average |
| TTFF cold start acquisition time | < 27 s average |
| Electrical characteristics | |
| Power supply | 5V/1A |
| Power socket | Standardised Micro USB type B plug |
| Battery | Li-Polymer, 2400 mAh |
| Battery working time after charging | 24 hours |
| Casing protection rating | IP67 |
| Physical characteristics | |
| Dimensions (HxWxT) | 121x60x30 mm |
| Housing | The waterproof and shock-resistant housing |
| Weight | 150g (GPS device) 30g (charger) |
| Motion sensor | 3-axis motion sensor (accelerometer) |
| Interfaces & general features | Internal speaker and microphone4 buttons for easy operatingAmbient operating temperature: -20°C to +60°CBased on durability-assumptions for Active GuardData transmission via GPRS (TCP, IP), SMS to OSM.2007Voice callSilent callRemote administration & firmware update |
| Configuration | Local: PC through RS232 link (LX cable and AGP3 programmer required)Remote: via GPRS, SMS, CSD |
| Alarm events buffer size | 1000 |
| Quantity of system events stored in history | 2000 |
